Black Jack Trailer Jack with wiring harness

Black Jack


Out of stock

Join the Waitlist



• 1600 kg lifting capacity, more than enough muscle
• Robust 58 mm outer post built for the toughest conditions (normal jockey wheels are only 48mm)
• Massive 560 mm stroke that will lift the caravan clear of the tow vehicle hitch in any conditions
• Built in level indicator to easily adjust the caravan level after you unhitch
• Removable foot pad extension for travelling
• Tough powder coated finish
• Emergency crank handle included as an emergency back up
• Built in night light for operating after hours
• 12 volt 28 amp DC power plugs directly to 12 volt battery
• Free installation kit included, easy DIY Installation (with BJTJ - 1001)
• Free all weather cover to keep the rain out
Total weight including Black Jack Clamp 17 kg

Black Jack wiring harness includes:

• 5 mtr Battery Cable
• Fuse Box
• 30 amp Fuse
• 2 x 10-6 Fuse Lug Terminals
• Cable Crimp Connector
• 10-8 Battery Lug Terminal
• Heat Shrink
• Black Jack Earth Lead to chassis
• Tek Screw for Earth to Chassis
• 4 x Black Jack Mounting Bolts
• 3 x Black Jack to Clamp nuts and bolts


• 6 different chassis bolt hole positions so it fits any Caravan or trailer A-Frame
• Multiple top hole positions so the Black Jack can be installed facing the front, the side or the rear of the Caravan or trailer. Your choice!
• Panel recess so you can install over the top of existing wire fittings maximizing the options of where to install on the A-Frame.
• Safety chain insert hole so you can hang safety chains on the Black Jack Clamp.
• Upper support and a lower support brackets designed to eliminate any lateral movement that may be caused by uneven surfaces.
• Easy bolt installation. No additional modifications, welding or tools are required.
• Tough powder coated finish
• Australian Patent Pending (No. 2020902039)
• Registered Australian Design

Comes with all weather cover and clamp and diy wiring harness kit.

SKU: AFTTITBJTJ-1001 TAG: Black Jack
